| Manufacturer |
AquaFlo/Gecko |
| Pump Model |
FMHP |
| Speed |
2 Speed (2-Spd) |
| Motor Voltage |
115v |
| Drain Plug Location |
6,9 o`clock |
| Suction Style |
Center |
| Suction Connection Type |
Female Pipe Thread (fpt), Male Buttress Thread (mbt) |
| Suction Pipe Size |
1-1/2" |
| Discharge Style |
Side |
| Discharge Connection Type |
Male Buttress Thread (mbt) |
| Discharge Pipe Size |
1-1/2" |
| Horsepower |
0.75hp |
| Motor Frame |
48 Frame Thru-Bolt |
| Motor Amperage/Wattage |
9.5A/3.2A |
- Horsepower: 0.75 HP
- Motor speed: 2-speed (high/low)
- Voltage: 115V
- Flow rate: 180 GPM (high) / 90 GPM (low)
- Suction size: 1.5"
- Discharge size: 1.5"
- Motor frame: 48 frame
- Impeller: High-performance impeller
- Construction: Reinforced engineered plastic
- Features: Long life shaft seal, built-in overload protection, adapts to hair and lint traps, stainless steel volute fasteners
This pump is a good choice for larger spas or spas with multiple jets. The 2-speed option allows you to choose the right flow rate for your needs, saving energy when you're not using the spa at full capacity. The high-performance impeller provides strong water flow, and the reinforced construction ensures durability.
Here are some additional details about the specifications:
- The flow rate is measured in gallons per minute (GPM). The higher the flow rate, the more water the pump can circulate per minute.
- The suction size is the diameter of the pipe that connects the pump to the spa's intake. The discharge size is the diameter of the pipe that connects the pump to the spa's output.
- The motor frame is a standard size used in many pumps.
- The impeller is the part of the pump that moves the water. A high-performance impeller can provide stronger water flow.
- The construction material is important for durability. Reinforced engineered plastic is a good choice for spa pumps because it is resistant to corrosion and wear.
