The Balboa 11774 (or 80-11774-K) is a 6-button self-adhesive overlay designed for the VL600S and VL620S series topside control panels. It is typically used for dual-pump configurations without an air blower.
Compatible Topside Control Panel
Topside Models: VL600, VL600S, VL620S, and ML553.
Common Part Numbers: Often paired with topside panels #54546, #54547, and #54548.
Shape: Rounded rectangle (oval-like).
Dimensions: Approximately 7.0" x 3.4".
Button Configuration
The 11774 overlay features a 6-button layout arranged around a central LCD screen cutout:
Left Side: Jets 1, Jets 2, Light.
Right Side: Warm, Mode, Cool.
Spa Manufacturers Using This Part
As a standardized Balboa component for dual-pump systems, it is used by a variety of manufacturers, including:
Artesian Spas / South Seas Spas: Frequently used in their multi-pump models.
Cal Spas: A standard option for dual-pump configurations.
Master Spas: Found in several high-performance lines.
Platinum Spas / Superior Wellness: Uses premium Balboa equipment across current lines.
Coast Spas: Incorporates these components in their multi-jet portable spas.
H2O Spas: Known to utilize Balboa control systems.
