| Motor Voltage |
115v |
| Speed |
2 Speed (2-Spd) |
| Motor Amperage/Wattage |
10.3A/3.8A |
| Horsepower |
1.0hp |
| Manufacturer |
Lingxiao (LX) Pump |
| Pump Model |
48WUA |
| Suction Pipe Size |
2" |
| Suction Connection Type |
Male Buttress Thread (mbt) |
| Suction Style |
Center |
| Discharge Pipe Size |
2" |
| Discharge Connection Type |
Male Buttress Thread (mbt) |
| Discharge Style |
Side |
| Motor Frame |
48 Frame Thru-Bolt |
| Drain Plug Location |
3,6,9 o`clock |
- Model: LX Pump 48WUA1001C-II
- Horsepower: 1 HP continuous
- Break horsepower: 1.5 HP
- Voltage: 115V
- Speed: 2-speed
- Flow rate: 122 GPM (high speed) / 61 GPM (low speed)
- Discharge size: 2"
- Suction size: 2"
- Drain plug location: 12 o'clock
- Pump to motor foot types: 48
- Suction style: Center suction
- Discharge style: Side discharge
- Warranty: 2 years
This pump is a good choice for small to medium-sized spas with up to 16 jets. It is a two-speed pump, so you can adjust the flow rate and pressure to your needs. It is also energy efficient, with a low operating cost.
Here are some additional details about the pump:
- The motor is a 48-frame induction motor with a capacitor start.
- The pump is made of cast iron and stainless steel, which makes it durable and corrosion-resistant.
- The pump comes with a set of unions, but you will need to purchase hoses separately.
Here are some of the key features of the 48WUA1001C-II spa pump:
- 2-speed operation for efficient water circulation
- Cast iron and stainless steel construction for durability
- Capacitor start motor for quiet operation
- Two sets of 2" unions included
- UL, CUL, and ETL certified
If you are looking for a reliable and efficient spa pump, the 48WUA1001C-II is a good option to consider.
